IRFK2D150 International Rectifier - MOSFET Module

IRFK2D150 Description

IRFK2D150 is an isolated base power HEX-pak MOSFET assembly, half bridge from International Rectifier, rated 100V, 72A.

USComponent supplies IRFK2D150 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

International Rectifier IRFK2D150 is used for high-frequency power switching in switch mode power supplies, DC-DC converters, battery-powered vehicles and equipment, welding machines and induction heating.

Key Specifications

IRFK2D150 is an isolated base power HEX-pak MOSFET assembly, half bridge from International Rectifier, rated 100V, 72A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	International Rectifier
Drain-source voltage VDS	100 V
Continuous drain current ID (TC = 25 °C)	72 A
ID (TC = 100 °C)	45 A
Pulse drain current IDM	288 A
On-resistance RDS(on)	28 mΩ
Max. power dissipation	500 W
Isolation voltage	2.5 kV rms, circuit to base
Configuration	Half bridge
Package	HEX-pak (TO-240), 140 g
Datasheet	Available on this page (PDF)

Note: data taken from the International Rectifier datasheet of IRFK2D150 / IRFK2F150 (D = fast switching), which covers IRFK2D150.
