MUBW30-12A6 IXYS - IGBT Module

MUBW30-12A6 Description

MUBW30-12A6 is a converter - brake - inverter module (CBI1), NPT IGBT from IXYS, rated 1200V, 31A. Typical applications: AC motor control and AC servo and robot drives.

USComponent supplies MUBW30-12A6 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

IXYS MUBW30-12A6 is used for AC motor control and AC servo and robot drives.

Key Specifications

MUBW30-12A6 is a converter - brake - inverter module (CBI1), NPT IGBT from IXYS, rated 1200V, 31A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	IXYS
Inverter VCES	1200 V
Inverter IC25	31 A
Inverter VCE(sat)	2.2 V
Brake VCES / IC25	1200 V / 18 A
Rectifier VRRM	1600 V
Rectifier IFAVM	25 A
Rectifier IFSM (10 ms)	370 A
Isolation voltage	2500 V~
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for MUBW30-12A6 (reply within 24 hours)
