IXFN44N100Q3 Description

IXFN44N100Q3 is a HiPerFET power MOSFET, Q3-class, N-channel, fast intrinsic rectifier from IXYS, rated 1000V, 38A.

USComponent supplies IXFN44N100Q3 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

IXYS IXFN44N100Q3 is used for DC-DC Converters, Battery Chargers, Switch-Mode and Resonant-Mode Power Supplies, DC Choppers and Temperature and Lighting Controls.

Key Specifications

IXFN44N100Q3 is a HiPerFET power MOSFET, Q3-class, N-channel, fast intrinsic rectifier from IXYS, rated 1000V, 38A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	IXYS
Drain-source voltage VDSS	1000 V
Drain current ID25 (TC = 25 °C)	38 A
Pulsed drain current IDM	110 A
On-resistance RDS(on)	≤ 220 mΩ
Reverse recovery trr	≤ 300 ns
Power dissipation PD	960 W
Isolation voltage	2500 V~ (1 min)
Package	miniBLOC (SOT-227) with aluminum nitride isolation
Datasheet	Available on this page (PDF)

Note: Datasheet marked Advance Technical Information.
