TT92N14KOF Infineon - Thyristor / Diode Module

TT92N14KOF Description

The TT92N14KOF from Infineon Technologies is a thyristor module with a 1400 V rating. It is used in phase-controlled rectifiers, soft starters, battery chargers and temperature controllers for furnaces and heaters. If you are repairing older equipment, we can usually find this exact part, including date codes that are no longer in production.

USComponent has sourced power semiconductors for maintenance teams and OEMs since 2001. For price and availability of the TT92N14KOF, send us a request for quote. Please confirm the specifications against the manufacturer's datasheet before purchase.

Summary of Features

TT92N14KOF is a 1400V 92A Thyristor Module.

Target Applications

Infineon TT92N14KOF is used for Soft starters, Rectifier for drive applications, Crowbar applications, Power controllers, Rectifiers for UPS, Battery chargers, Static transfer switches and Bypass switches.

Key Specifications

Manufacturer	Infineon Technologies (eupec)
Configuration	Phase control thyristor module, two thyristors (TT)
VDRM / VRRM	1400 V
ITAVM	92 A (TC = 85 °C)
ITRMSM	160 A
ITSM	2050 A (25 °C) / 1800 A (Tvj max), 10 ms
I²t	21,000 A²s (25 °C, 10 ms)
Critical di/dt	150 A/µs
Critical dv/dt	1000 V/µs
On-state voltage vT max.	1.62 V @ 300 A
Gate trigger current / voltage	120 mA / 1.4 V max.
Turn-off time tq typ.	150 µs
Isolation test voltage	2.5 kV RMS (1 min)
Mounting torque	4 Nm (±15%)
Terminal torque	4 Nm (±10%)
Weight	160 g
Junction temperature	130 °C max.

TT92N14KOF Video
