TD570N16KOF Infineon - Thyristor / Diode Module

TD570N16KOF Description

TD570N16KOF is a phase control thyristor / diode module (TD570N) from Infineon (eupec / IFBIP), rated 1600V, 600A. Typical applications: Soft starter, rectifier for drives applications, crowbar applications, power controllers, rectifiers for UPS, battery chargers, static switches and bypass switches.

USComponent supplies TD570N16KOF and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

Infineon TD570N16KOF is used for Soft starter, rectifier for drives applications, crowbar applications, power controllers, rectifiers for UPS, battery chargers, static switches and bypass switches.

Key Specifications

TD570N16KOF is a phase control thyristor / diode module (TD570N) from Infineon (eupec / IFBIP), rated 1600V, 600A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	Infineon (eupec / IFBIP)
Repetitive peak off-state / reverse voltage VDRM, VRRM	1600 V
Non-repetitive peak reverse voltage VRSM	1700 V
Average on-state current ITAVM	600 A (TC = 85 °C)
Max. RMS on-state current ITRMSM	900 A
Surge current ITSM (10 ms, 25 °C / Tvj max)	17000 A / 14000 A
I²t (10 ms, 25 °C)	1 445 000 A²s
On-state voltage vT max. (1500 A, Tvj max)	1.27 V
Critical rate of rise of off-state voltage	1000 V/µs
Base plate / weight	60 mm / 1450 g
Datasheet	Available on this page (PDF)

Note: data taken from the Infineon (eupec / IFBIP) datasheet of TT570N16KOF / TD570N16KOF, which covers TD570N16KOF.
