ND600N14 Infineon - Power Transistor Module
ND600N14 Description
Infineon Technologies (formerly Eupec) makes the ND600N14, a thyristor (SCR). Typical applications include soft starters, AC power controllers, controlled rectifiers, DC motor drives and heating control.
Request a quote for the ND600N14 and our team will get back to you with price, quantity available and lead time. We ship worldwide. As with any power device, please check the manufacturer's datasheet to confirm it matches your design.
Target Applications
Infineon ND600N14 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.
Key Specifications
ND600N14 is an eupec (Infineon) PowerBLOCK diode module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).
| Parameter | Value |
|---|---|
| Manufacturer | eupec (Infineon Technologies) |
| Product type | PowerBLOCK diode module |
| Repetitive peak reverse voltage (VRRM) | 1400 V (series 1200 to 1800 V) |
| Average forward current (IFAVM), 180° el sin | 600 A at Tc = 100 °C |
| RMS current (IFRMSM) | 950 A |
| Surge current (IFSM), 10 ms, Tvj max | 19000 A |
| I²t, 10 ms, Tvj max | 1800 × 10³ A²s |
| Threshold voltage V(T0) | 0.75 V |
| Slope resistance rT | 0.215 mΩ |
| Thermal resistance RthJC | 0.078 °C/W |
| Thermal resistance RthCK | 0.02 °C/W |
| Max. junction temperature Tvj max | 150 °C |
| Package (outline) | DP60 |
Technical document (PDF) | Request a quote for ND600N14 (reply within 24 hours)
Related Part Numbers
| ND600N16 1600V, 600A | ND600N12 1200V, 600A | ND600N18 1800V, 600A | ND350N14 1400V, 350A |
| ND260N14 1400V, 260A | ND350N12 1200V, 350A | ND350N16 1600V, 350A | ND350N18 1800V, 350A |
| ND600N14K 1400V, 600A | ND600N12K 1200V, 600A | ND600N16K 1600V, 600A | ND600N06K 600V, 600A |
| ND600N04K 400V, 600A | ND600N18K 1800V, 600A | ND600N02K 200V, 600A | ND89N08K 800V |
