FZ600R12KE3S Infineon - IGBT
FZ600R12KE3S Description
The Infineon FZ600R12KE3S is an IGBT, rated for 1200 V. Engineers use it mainly in the inverter section of motor drives, as well as in UPS, welding and power-conversion equipment. Many of these parts are still in service in machines built years ago, and a direct replacement is often the fastest way to get one running again.
USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the FZ600R12KE3S, and please confirm ratings against the datasheet before ordering.
Target Applications
Infineon FZ600R12KE3S is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.
Key Specifications
FZ600R12KE3S is an eupec (Infineon) IGBT standard module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).
| Parameter | Value |
|---|---|
| Manufacturer | eupec (Infineon Technologies) |
| Product type | IGBT standard module |
| Collector-emitter voltage VCES | 1200 V |
| Collector current IC | 600 A |
| VCE(sat) typ., Tvj = 25 °C | 1.7 V |
| Total power dissipation Ptot | 2500 W |
| Thermal resistance RthJC per arm | ≤ 0.05 K/W |
| Package (outline) | IS10a |
Technical document (PDF) | Request a quote for FZ600R12KE3S (reply within 24 hours)
Related Part Numbers
| FZ400R12KE3S 1200V, 400A | FZ600R12KE3 1200V, 600A | FZ500R12KE3 1200V, 500A | FZ800R12KE3 1200V, 800A |
| FZ600R12KE4 600A/1200V | FZ600R17KE3 1700V, 600A | FZ400R12KE3 1200V, 400A | FZ900R12KE3 1200(V) / 900(A) |
| FZ600R12KF2 1200V, 600A | FZ600R12KP4 1200V, 600A | FZ600R12KS4 1200V, 600A | FZ600R12KS4-ENG 1200(V) / 600(A) |
| FZ600R17KE3_S4 1700V, 600A | FZ600R17KE4 1700V, 600A | FZ600R65FK1 6500V, 600A | FZ600R65KE3 600A/6500V |
