FP30R06KE3 Infineon - IGBT Module

FP30R06KE3 Description

Infineon Technologies makes the FP30R06KE3, a 600 V, 30 A IGBT module. Inside, it has a PIM layout, with the input rectifier, brake chopper and three-phase inverter in one package. Modules like this do the heavy switching in motor drives, UPS systems, induction heaters and renewable-energy inverters.

Need the FP30R06KE3? USComponent stocks and sources power modules for repair shops, OEMs and maintenance teams worldwide. Request a quote and we'll confirm availability and lead time. Always compare against the datasheet before ordering.

Summary of Features

Target Applications

Infineon FP30R06KE3 is used for Auxiliary Inverters, High Power Converters, Motor Drives, Traction Drives, UPS Systems and Wind Turbines.

Key Specifications

FP30R06KE3 is a 600 V, 30 A IGBT module, pIM (converter + brake + inverter) configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	PIM (converter + brake + inverter)
Collector-emitter voltage (VCES)	600 V
Collector current (IC)	30 A
Datasheet	Available on this page (PDF)

Replacement for discontinued parts: Infineon recommends FP30R06KE3 as the replacement for BSM10GP60, BSM15GP60 (Product Discontinuation PD_257_19). Check the datasheet limits and pinout when replacing.

Status: end of life announced by Infineon (Product Discontinuation PD_26_161_01, issued 2026-09-11: last order date 2027-03-15, last delivery date 2027-09-15). Infineon lists no direct replacement for this part. USComponent can still source the original FP30R06KE3.

Technical document (PDF)  |  Request a quote for FP30R06KE3 (reply within 24 hours)
