BSM30GD60DLCInfineon - IGBT Module

BSM30GD60DLC Description

The Infineon Technologies BSM30GD60DLC is an IGBT module, available from USComponent. Typical applications for this type of device include variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent, a BBB A+ accredited business, helps engineers and maintenance teams source power semiconductors and industrial components, including older and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the BSM30GD60DLC.

Target Applications

Infineon BSM30GD60DLC is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

Manufacturer	Infineon Technologies (eupec)
Configuration	Three-phase full bridge (six-pack) IGBT module
Technology	Low-loss IGBT2 (DLC)
VCES	600 V
IC	30 A (TC = 70 °C) / 40 A (TC = 25 °C)
Diode I²t	240 A²s (10 ms, 125 °C)
Isolation test voltage	2.5 kV RMS, 50 Hz, 1 min
