BSM15GP120-B2 Infineon - IGBT

BSM15GP120-B2 Description

The BSM15GP120-B2 from Infineon Technologies (formerly Eupec) is an IGBT module. Engineers use it mainly in the inverter section of motor drives, as well as in UPS, welding and power-conversion equipment.

USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the BSM15GP120-B2, and please confirm ratings against the datasheet before ordering.

Summary of Features

Target Applications

Infineon BSM15GP120-B2 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

BSM15GP120-B2 is an eupec (Infineon) IGBT power integrated module (PIM). Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF). BSM15GP120-B2 is a variant of the basic type BSM15GP120; the values are those listed for BSM15GP120.

Parameter	Value
Manufacturer	eupec (Infineon Technologies)
Product type	IGBT power integrated module (PIM)
Inverter IGBT: VCES	1200 V
Inverter IGBT: IC	15 A
Inverter IGBT: RthJC	0.70 K/W
Inverter IGBT: VCE(sat), Tvj = 25 °C	2.20 V
Rectifier diodes: VRRM	1600 V
Rectifier diodes: Id, Tc = 80 °C	15 A
Rectifier diodes: RthJC	1.20 K/W
Rectifier diodes: Vto / rT, Tvj = 150 °C	0.8 V / 10.5 mΩ
Brake chopper: VCES	1200 V
Brake chopper: IC, Tc = 80 °C	10.0 A
Brake chopper: RthJC	1.2 K/W
Package (outline)	IS12

Technical document (PDF)  |  Request a quote for BSM15GP120-B2 (reply within 24 hours)
