BSM10GP120_B9 Infineon - IGBT Module

BSM10GP120_B9 Description

The BSM10GP120_B9 is an IGBT module made by Infineon Technologies. The module contains a PIM layout, with the input rectifier, brake chopper and three-phase inverter in one package. Engineers use it mainly in the inverter section of motor drives, as well as in UPS, welding and power-conversion equipment.

We help engineers and repair technicians find parts like the BSM10GP120_B9, including obsolete ones. Send a quick RFQ for current pricing and delivery. Before ordering, please confirm ratings and pin-out with the official datasheet.

Summary of Features

Target Applications

Infineon BSM10GP120_B9 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

BSM10GP120_B9 is a 1,200 V, 10 A IGBT module, pIM configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	PIM
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	10 A
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for BSM10GP120_B9 (reply within 24 hours)
