BSM100GB120DN11Infineon - IGBT Module

BSM100GB120DN11 Description

The Infineon Technologies BSM100GB120DN11 is an IGBT module. Typical applications for this type of device include variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent specializes in sourcing power modules and industrial electronic components, including legacy and hard-to-find parts for repair and maintenance. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the BSM100GB120DN11.

Target Applications

Infineon BSM100GB120DN11 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

Manufacturer	Infineon Technologies (formerly Eupec)
Configuration	Dual / half-bridge (2-in-1)
VCES	1200 V
IC nom	100 A
Similar-rating parts	CM100DU-24NFH, CM100DY-24NF, CM100DU-24F, 2MBI100S-120, BSM100GB120DN2K, BSM100GB120DN2, FF100R12KS4, BSM100GB120DLC (same nominal voltage and current rating, for reference only. Package, pinout and characteristics may differ; please compare datasheets to determine suitability)

BSM100GB120DN11 Video

Download BSM100GB120DN11 Datasheet

Datasheet not available
