MBN1000FH45F Hitachi - IGBT Module

MBN1000FH45F Description

MBN1000FH45F is a 4,500 V / 1,000 A single igbt module in the MBN / MBM / MBL family from Hitachi Power Semiconductor Device / MinebeaMitsumi. Manufacturer catalog lists this model in mass production. Verify electrical ratings, package, terminals, isolation and exact ordering suffix against the manufacturer datasheet before ordering.

USComponent sources industrial power semiconductor modules including hard-to-find parts. Request a quote for MBN1000FH45F price and availability.

Summary of Features

Target Applications

Hitachi MBN1000FH45F finds applications in various industries and systems where high power switching is required.

Key Specifications

MBN1000FH45F is listed in the official Hitachi Power Semiconductor Device / MinebeaMitsumi power module catalog.

Parameter	Value
Manufacturer	Hitachi Power Semiconductor Device / MinebeaMitsumi
Part number	MBN1000FH45F
Series	MBN / MBM / MBL
Device type	Single IGBT module
Rated VCES	4,500 V
Catalog current rating	1,000 A
Manufacturer catalog status	Mass production
Official source	Manufacturer product lineup

Specifications are from the manufacturer lineup, not a verified complete product-specific datasheet. Confirm pinout, mechanical fit, gate-drive requirements and current ordering status.

Technical document (PDF)  |  Request a quote for MBN1000FH45F (reply within 24 hours)
