6MBP150NA060 Fuji Electric - IGBT module

6MBP150NA060 Description

Fuji Electric makes the 6MBP150NA060, a 600 V, 150 A intelligent power module (IPM). It is mostly used in small and mid-size AC drives and servo amplifiers, where built-in gate drive and protection save board space.

Request a quote for the 6MBP150NA060 and our team will get back to you with price, quantity available and lead time. We ship worldwide. As with any power device, please check the manufacturer's datasheet to confirm it matches your design.

Summary of Features

6MBP150NA060 is a 600V 150A IPM.

Target Applications

Fuji Electric 6MBP150NA060 is used for General Purpose Inverter, Uninterruptible Power Supply, Server Spindle Drive for CNC Machine Tool, Robotic, Welding Machines.

Key Specifications

Manufacturer	Fuji Electric
Configuration	IGBT-IPM, N-Series, six-pack (three-phase inverter)
Built-in protection	Over-heating protection by direct junction temperature detection
DC bus voltage	450 V (surge 500 V)
VCES	600 V
IC	150 A DC (ICP 300 A)
Isolation voltage	AC 2.5 kV (case-terminal)
Mounting torque	M5: 3.5 N·m
