7MBP50NA060 Fuji Electric - IGBT power module

7MBP50NA060 Description

Rated at 600 V and 50 A, the Fuji Electric 7MBP50NA060 is an intelligent power module (IPM). Inside, it has a PIM layout, with the input rectifier, brake chopper and three-phase inverter in one package. Because the gate drivers and protection circuits are built in, it is popular in compact motor drives, servo amplifiers and appliance inverters.

USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the 7MBP50NA060; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.

Summary of Features

Target Applications

Fuji Electric 7MBP50NA060 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

7MBP50NA060 is a 600 V, 50 A intelligent power module (IPM), 7-in-1 (with brake) configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	Intelligent power module (IPM)
Configuration	7-in-1 (with brake)
Collector-emitter voltage (VCES)	600 V
Collector current (IC)	50 A
Datasheet	Available on this page (PDF)

7MBP50NA060 Video
