2MBI300U4H-170 Fuji Electric - IGBT power module

2MBI300U4H-170 Description

2MBI300U4H-170 is an IGBT module (U4 series), 2 in one package from Fuji Electric, rated 1700V, 300A.

USComponent supplies 2MBI300U4H-170 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Target Applications

Fuji Electric 2MBI300U4H-170 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

2MBI300U4H-170 is an IGBT module (U4 series), 2 in one package from Fuji Electric, rated 1700V, 300A. Source: manufacturer datasheet.

Note: data taken from the Fuji Electric datasheet of Fuji Electric specification sheet MS5F6137, which covers 2MBI300U4H-170.

Note: Nominal rating 300 A at Tc = 80 °C (400 A at 25 °C).

Technical document (PDF)  |  Request a quote for 2MBI300U4H-170 (reply within 24 hours)
