2MBI150-060Fuji Electric - IGBT power module

2MBI150-060 Description

Fuji Electric 2MBI150-060 is an IGBT module rated at 600 V and 150 A. This type of device is widely used in variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent specializes in sourcing power modules and industrial electronic components, including legacy and hard-to-find parts for repair and maintenance. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the 2MBI150-060.

Target Applications

Fuji Electric 2MBI150-060 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

Manufacturer	Fuji Electric
Configuration	Dual / half-bridge (2-in-1)
VCES	600 V
IC nom	150 A
Similar-rating parts	CM150DY-12NF, CM150DU-12F, BSM150GB60DLC, CM150DY-12E, CM150DU-12H, CM150DY12E, 2MBI150NC-060 (same nominal voltage and current rating, for reference only. Package, pinout and characteristics may differ; please compare datasheets to determine suitability)

2MBI150-060 Video

Download 2MBI150-060 Datasheet

Datasheet not available
