1MBI300JN-140Fuji Electric - IGBT Module

1MBI300JN-140 Description

The Fuji Electric 1MBI300JN-140 is an IGBT module rated at 1400 V and 300 A, available from USComponent. Components of this type are commonly used in variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent specializes in sourcing power modules and industrial electronic components, including legacy and hard-to-find parts for repair and maintenance. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the 1MBI300JN-140.

Target Applications

Fuji Electric 1MBI300JN-140 is used for Inverter for Motor Drive, AC and DC Servo Drive Amplifier, Uninterruptible Power Supply, Industrial Machines, such as Welding Machines.

Key Specifications

Manufacturer	Fuji Electric
Configuration	Single switch (1-in-1)
VCES	1400 V
IC nom	300 A
Similar-rating parts	CM300HA-28 (same nominal voltage and current rating, for reference only. Package, pinout and characteristics may differ; please compare datasheets to determine suitability)

1MBI300JN-140 Video

Download 1MBI300JN-140 Datasheet

Datasheet not available
