BSM100GAL120DLCKInfineon (Eupec) - IGBT Module

BSM100GAL120DLCK Description

The Infineon Technologies (formerly Eupec) BSM100GAL120DLCK is an IGBT module. Typical applications for this type of device include variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent, a BBB A+ accredited business, helps engineers and maintenance teams source power semiconductors and industrial components, including older and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the BSM100GAL120DLCK.

Target Applications

Infineon (Eupec) BSM100GAL120DLCK is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

Manufacturer	Infineon Technologies (eupec)
Configuration	Chopper IGBT module (GAL)
Technology	Low-loss IGBT2 (DLC)
VCES	1200 V
IC	100 A (TC = 80 °C) / 205 A (TC = 25 °C)
ICRM	200 A (tp = 1 ms)
Diode IFRM	200 A (tp = 1 ms)
Isolation test voltage	2.5 kV RMS, 50 Hz, 1 min
