MP6754 Toshiba - IGBT Module

MP6754 Description

MP6754 is a GTR module, 6 IGBTs in 1 package from Toshiba, rated 600V, 10A. Typical applications: High power switching applications and motor control applications.

USComponent supplies MP6754 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

Toshiba MP6754 is used for High power switching applications and motor control applications.

Key Specifications

MP6754 is a GTR module, 6 IGBTs in 1 package from Toshiba, rated 600V, 10A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	Toshiba
Collector-emitter voltage VCES	600 V
Collector current IC (DC)	10 A
ICP (1 ms)	20 A
VCE(sat) max. (IC = 10 A)	4.0 V
Fall time tf max. (IC = 10 A)	0.35 µs
Collector power dissipation (Tc = 25 °C)	40 W
Isolation voltage	2500 V (AC 1 min)
Package / weight	TOSHIBA 2-78A1A, 44 g
Datasheet	Available on this page (PDF)
