MIG20J105LToshiba - Intelligent Power Module

MIG20J105L Description

The Toshiba MIG20J105L is an intelligent power module (IPM) rated at 600 V and 20 A. Components of this type are commonly used in compact motor drives, servo amplifiers and inverter-based equipment, where the IPM combines power switches with built-in gate drive and protection circuitry.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the MIG20J105L.

Target Applications

Toshiba MIG20J105L is used for High Power Switching Applications and Motor Control Applications.

Key Specifications

Manufacturer	Toshiba
Category	Intelligent Power Module
Rated voltage	600 V
Rated current	20 A

Download MIG20J105L Datasheet

Datasheet not available
