MIG100J6CSB1WToshiba - Intelligent Power Module

MIG100J6CSB1W Description

The Toshiba MIG100J6CSB1W is an intelligent power module (IPM) rated at 600 V and 100 A. Intelligent Power Module Silicon N Channel IGBT. Components of this type are commonly used in compact motor drives, servo amplifiers and inverter-based equipment, where the IPM combines power switches with built-in gate drive and protection circuitry.

USComponent specializes in sourcing power modules and industrial electronic components, including legacy and hard-to-find parts for repair and maintenance. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the MIG100J6CSB1W.

Target Applications

Toshiba MIG100J6CSB1W is used for compact inverter stages in AC motor drives, servo amplifiers, air conditioner and appliance inverters, elevators and general purpose inverters.

Key Specifications

Manufacturer	Toshiba
Category	Intelligent Power Modules
Rated voltage	600 V
Rated current	100 A

Download MIG100J6CSB1W Datasheet

Datasheet not available
