SKM150GAL12T4

SKM150GAL12T4 Description

is an insulated gate bipolar transistor (IGBT) module designed for use in high-power industrial applications. It is manufactured by Semikron, a leading supplier of power electronics. The SKM150GAL12T4 IGBT module consists of two IGBTs and two antiparallel diodes in a half-bridge configuration. It operates at a voltage rating of 1200V and a current rating of 150A. The IGBT module features a high-performance design that provides fast switching speeds and low conduction losses, resulting in high efficiency and reliable performance. It includes a range of protection features to ensure safe and reliable operation, including overcurrent protection and thermal protection. The SKM150GAL12T4 IGBT module is designed for easy integration into existing industrial systems, with a variety of mounting options available including screw terminals and pressure contacts. It is also compatible with a range of heat sink options to provide efficient cooling.

Summary of Features

SKM150GAL12T4 is a(n) . 1200V, 150A.

Target Applications

Semikron SKM150GAL12T4 finds applications in various industries and systems where high power switching is required.

Download SKM150GAL12T4 Datasheet

Datasheet not available
