SKKD162-18 Semikron - Power Transistor Module

SKKD162-18 Description

Semikron SKKD162-18 is a diode module rated at 1800 V and 195 A. Typical applications include AC-to-DC rectification in drives and power supplies, freewheeling paths and battery charging.

USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the SKKD162-18; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.

Summary of Features

Target Applications

Semikron SKKD162-18 is used for AC/AC converters, line rectifiers for transistorized AC motor controllers, AC motor controllers and field supply for DC motors.

Key Specifications

SKKD162-18 is a 1,800 V, 160 A diode module (dual). Source: manufacturer datasheet (Semikron).

Parameter	Value
Product type	Diode module (dual)
Repetitive peak reverse voltage (VRRM / VDRM)	1,800 V
Non-repetitive peak reverse voltage (VRSM)	1,900 V
Average on-state / forward current	160 A (sin. 180°, Tc = 95 °C)
RMS current, max. (continuous)	310 A
Surge current (10 ms, Tvj = 125 °C)	5,000 A
On-state / forward voltage, max. (Tvj = 25 °C)	1.5 V
Isolation test voltage (Visol, a.c. 50 Hz)	3600 / 3000 V~
Weight	approx. 165 g
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for SKKD162-18 (reply within 24 hours)
