SKET800-14GH4 Semikron - Thyristor Module

Also written as: SKET80014GH4

Category: Thyristor & SCR Modules

Specifications: 1400(V) / 805(A)

SKET800-14GH4 Semikron Thyristor Module

We beat competitor's price with faster delivery.

For 6 pieces or more, submit your inquiry here, email to sales@uscomponent.com or call 1-281-968-0718

SKET800-14GH4 Description

Semikron SKET800-14GH4 is a thyristor module. Common uses are AC switches, soft starters, DC drives and controlled rectifiers in industrial power equipment.

We help engineers and repair technicians find parts like the SKET800-14GH4, including obsolete ones. Send a quick RFQ for current pricing and delivery. Before ordering, please confirm ratings and pin-out with the official datasheet.

Summary of Features

  • Thyristor with amplifying gate
  • UL recognized, file no. E63532

Target Applications

Semikron SKET800-14GH4 is used for DC motor control (e.g. for machine tools) and temperature control (e.g. for ovens, chemical processes).

Key Specifications

SKET800-14GH4: key data from the Semikron datasheet.

ParameterValue
Average on-state / forward current805 A (sin. 180°, Tc = 85 °C)
RMS current, max. (continuous)1,500 A
Surge current (10 ms, Tvj = 130 °C)32,000 A
PackageSEMIPACK 6
Weightapprox. 2150 g
DatasheetAvailable on this page (PDF)

Technical document (PDF)  |  Request a quote for SKET800-14GH4 (reply within 24 hours)
