KD221205A7Powerex - Power Transistor Module

KD221205A7 Description

The Powerex KD221205A7 is a Darlington transistor module rated at 1200 V and 50 A, available from USComponent. Darlington Half Bridge Power Module – 3-Stage Viso 2.5kV(RMS) BJT Dual Darlington NPN Transistor Module 50 Ampers/1200 Volts. This type of device is widely used in motor drives, UPS systems and power supplies; transistor modules of this type are largely superseded by IGBTs in new designs but remain essential for maintaining installed equipment.

USComponent, a BBB A+ accredited business, helps engineers and maintenance teams source power semiconductors and industrial components, including older and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the KD221205A7.

Target Applications

Powerex KD221205A7 is used for AC Motor Control, DC Motor Control, Switching Power Supplies and Inverters.

Key Specifications

Manufacturer	Powerex
Category	Power Transistor Modules
Rated voltage	1200 V
Rated current	50 A

Download KD221205A7 Datasheet

KD221205A7 PDF Datasheet
