QM100TF-HB Mitsubishi - Power Transistor Module

QM100TF-HB Description

The QM100TF-HB from Mitsubishi Electric is a Darlington transistor module with a 600 V / 100 A rating. You will mostly see it in older AC drives, servo amplifiers and UPS systems, where a like-for-like replacement keeps the machine running.

USComponent has been supplying power semiconductors since 2001, including discontinued and hard-to-find part numbers. Send us an RFQ for the QM100TF-HB and we will reply with price, condition and lead time. Please check the manufacturer's datasheet to confirm ratings, package and pin-out before you order.

Summary of Features

Target Applications

Mitsubishi QM100TF-HB is used for Power switching, AC motor control, DC motor control and UPS.

Key Specifications

QM100TF-HB is a 100 A power transistor (bipolar Darlington) module. Source: manufacturer datasheet.

Parameter	Value
Product type	Power transistor (bipolar Darlington) module
Collector current (IC)	100 A
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for QM100TF-HB (reply within 24 hours)
