PS21869 Mitsubishi - Intelligent Power Module

Category: Intelligent Power Modules (IPM)

Specifications: 600V, 50A

PS21869 Intelligent Power Module from MITSUBISHI

We beat competitor's price with faster delivery.

For 6 pieces or more, submit your inquiry here, email to sales@uscomponent.com or call 1-281-968-0718

PS21869 Description

PS21869 is a dual-in-line package intelligent power module (DIP-IPM), CSTBT from Mitsubishi Electric, rated 600V, 50A. Typical applications: AC100 V~200 V three-phase inverter drive for small power motor control.

USComponent supplies PS21869 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

  • 600 V / 50 A low-loss CSTBT inverter bridge for 3 phase DC-to-AC power conversion
  • Integrated drive, protection and system control functions
  • Upper-leg IGBTs: drive circuit, high voltage isolated high-speed level shifting, under-voltage protection
  • Lower-leg IGBTs: drive circuit, under-voltage and short circuit protection
  • Fault signaling output
  • Input interface: 5 V line CMOS/TTL compatible (high active)
  • UL approved (E80276)

Target Applications

Mitsubishi PS21869 is used for AC100 V~200 V three-phase inverter drive for small power motor control.

Key Specifications

PS21869 is a dual-in-line package intelligent power module (DIP-IPM), CSTBT from Mitsubishi Electric, rated 600V, 50A. Source: manufacturer datasheet.

ParameterValue
ManufacturerMitsubishi Electric
Collector-emitter voltage VCES600 V
Each IGBT collector current ±IC50 A
±ICP (< 1 ms)100 A
Supply voltage VCC (P-N)450 V
Isolation voltage2500 Vrms
PackageTransfer-mold, insulated
DatasheetAvailable on this page (PDF)

Note: data taken from the Mitsubishi Electric datasheet of PS21869 / PS21869-A, which covers PS21869.

Technical document (PDF)  |  Request a quote for PS21869 (reply within 24 hours)
