PS12018-A Mitsubishi - Power Transistor Module

Category: Intelligent Power Modules (IPM)

Specifications: 1200V, 25A

PS12018-A Mitsubishi Power Transistor Module

We beat competitor's price with faster delivery.

For 6 pieces or more, submit your inquiry here, email to sales@uscomponent.com or call 1-281-968-0718

PS12018-A Description

PS12018-A is an application specific intelligent power module (ASIPM), 3-phase inverter + brake, 1200 V class from Mitsubishi Electric, rated 1200V, 25A. Typical applications: Acoustic noise-less 3.7 kW / AC400 V class 3-phase inverter and other motor control applications.

USComponent supplies PS12018-A and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

  • 3-phase IGBT inverter bridge configured by 3rd generation IGBT and diode technologies
  • Circuit for dynamic braking of motor regenerative energy
  • Integrated drive, protection and system control functions
  • Built-in high-speed photo-couplers for direct coupling to CPU

Target Applications

Mitsubishi PS12018-A is used for Acoustic noise-less 3.7 kW / AC400 V class 3-phase inverter and other motor control applications.

Key Specifications

PS12018-A is an application specific intelligent power module (ASIPM), 3-phase inverter + brake, 1200 V class from Mitsubishi Electric, rated 1200V, 25A. Source: manufacturer datasheet.

ParameterValue
ManufacturerMitsubishi Electric
IGBT collector-emitter voltage1200 V
Supply voltage VCC (P-N)900 V
Each output IGBT collector current ±Ic (±Icp)±25 A (±50 A)
Brake IGBT collector current10 A (20 A)
Inverter output current Io9.2 A rms (100%), 13.8 A rms 150% overload 1 min
Isolation voltage2500 Vrms
PackageFlat-base type, insulated
DatasheetAvailable on this page (PDF)

Note: Datasheet marked preliminary.

Technical document (PDF)  |  Request a quote for PS12018-A (reply within 24 hours)
