IRFK6H150 Description

IRFK6H150 is an isolated base power HEX-pak MOSFET assembly, parallel chip from International Rectifier, rated 100V, 150A.

USComponent supplies IRFK6H150 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

International Rectifier IRFK6H150 is used for AC motor speed control, DC servo and robot drives, Uninterruptible power system (UPS), Switch-mode and resonant-mode power supplies and DC choppers.

Key Specifications

IRFK6H150 is an isolated base power HEX-pak MOSFET assembly, parallel chip from International Rectifier, rated 100V, 150A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	International Rectifier
Drain-source voltage VDS	100 V
Continuous drain current ID (TC = 25 °C)	150 A
ID (TC = 100 °C)	120 A
Pulse drain current IDM	720 A
On-resistance RDS(on)	10 mΩ
Max. power dissipation	625 W
Isolation voltage	2.5 kV rms, circuit to base
Configuration	Parallel chip
Package	HEX-pak (TO-240), 140 g
Datasheet	Available on this page (PDF)

Note: data taken from the International Rectifier datasheet of IRFK6H150 / IRFK6J150 (H = fast switching), which covers IRFK6H150.
