N1400CH16IXYS - Thyristor Module

N1400CH16 Description

N1400CH16 is a Silicon Controlled Rectifier (SCR) manufactured by ON Semiconductor. SCRs are semiconductor devices used for controlling and regulating the flow of electric current in high-power applications, such as motor drives, power supplies, and industrial heating systems. They can handle high voltage and current levels and are capable of switching on and off quickly. The N1400CH16 SCR has a blocking voltage of 1600V and a current rating of 1400A. It is a high-performance device designed for use in high-power applications. The SCR has a gate-controlled turn-on and a reverse blocking capability that makes it suitable for use in applications requiring high reliability and ruggedness. The device has a compact and robust package design, with a ceramic disc insulator for electrical isolation and a copper base plate for high thermal conductivity. The package is rated for high temperature operation and is suitable for use in harsh environments. Overall, the N1400CH16 SCR is a high-performance and reliable device suitable for demanding applications that require high power density and efficient operation. Its high current rating and blocking voltage make it ideal for use in motor control, power supplies, and industrial heating systems. The device has a low on-state voltage drop, which results in low power dissipation and high efficiency.

Target Applications

IXYS N1400CH16 finds applications in various industries and systems where high power switching is required.

Key Specifications

Manufacturer	IXYS
Category	Thyristor Modules
Rated voltage	1600 V
Rated current	5565.65 A

Download N1400CH16 Datasheet

Datasheet not available
