TT162N12KOF Infineon - Thyristor Module

TT162N12KOF Description

The TT162N12KOF from Infineon Technologies is a thyristor module with a 1200 V / 162 A rating. You'll find thyristors like this in soft starters, static switches, DC motor controllers and heater controls.

Request a quote for the TT162N12KOF and our team will get back to you with price, quantity available and lead time. We ship worldwide. As with any power device, please check the manufacturer's datasheet to confirm it matches your design.

Target Applications

Infineon TT162N12KOF is used for Motor control and drives, Wind energy systems, Traction, Commercial, construction and agricultural vehicles (CAV), Uninterruptible power supply (UPS) and Industrial heating and welding.

Key Specifications

Manufacturer	Infineon Technologies (eupec)
Configuration	Phase control thyristor module, two thyristors (TT)
VDRM / VRRM	1200 V
ITAVM	162 A (TC = 85 °C)
ITRMSM	260 A
ITSM	5200 A (25 °C, 10 ms)
I²t	135,000 A²s (25 °C, 10 ms)
On-state voltage vT max.	1.41 V @ 500 A
Gate trigger current / voltage	150 mA / 2 V max.
Turn-off time tq typ.	200 µs
Isolation test voltage	2.5 kV RMS (1 min)
Mounting torque	6 Nm (±15%)
Terminal torque	6 Nm (±10%)
Weight	310 g
Junction temperature	125 °C max.
