TD330N16KOF Infineon - Thyristor / Diode Module

TD330N16KOF Description

Rated at 1600 V and 330 A, the Infineon Technologies TD330N16KOF is a thyristor module. You'll find thyristors like this in soft starters, static switches, DC motor controllers and heater controls.

Need the TD330N16KOF? USComponent stocks and sources power modules for repair shops, OEMs and maintenance teams worldwide. Request a quote and we'll confirm availability and lead time. Always compare against the datasheet before ordering.

Summary of Features

Target Applications

Infineon TD330N16KOF is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

TD330N16KOF is an eupec (Infineon) PowerBLOCK thyristor/diode module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).

Parameter	Value
Manufacturer	eupec (Infineon Technologies)
Product type	PowerBLOCK thyristor/diode module
Repetitive peak off-state / reverse voltage (VDRM / VRRM)	1600 V (series 1200 to 1600 V)
Average on-state current (ITAVM), 180° el sin	330 A at Tc = 85 °C
RMS current (ITRMSM)	520 A
Surge current (ITSM), 10 ms, Tvj max	8000 A
I²t, 10 ms, Tvj max	320 × 10³ A²s
Threshold voltage V(T0)	0.80 V
Slope resistance rT	0.60 mΩ
Critical rate of rise of on-state current (di/dt)cr	250 A/µs
Turn-off time tq, typ.	250 µs
Critical rate of rise of off-state voltage (dv/dt)cr	1000 V/µs
Thermal resistance RthJC	0.117 °C/W
Thermal resistance RthCK	0.04 °C/W
Max. junction temperature Tvj max	135 °C
Package (outline)	TP50

Technical document (PDF)  |  Request a quote for TD330N16KOF (reply within 24 hours)
