T3441N52TOH Infineon - Phase Control SCR

T3441N52TOH Description

T3441N52TOH is a phase control thyristor, disc (press-pack) from Infineon (eupec / IFBIP), rated 5200V, 3200A. Typical applications: Static Var Compensation (SVC), rectifier for drives applications, medium voltage drives, load commutating inverter and cycloconverter.

USComponent supplies T3441N52TOH and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

Infineon T3441N52TOH is used for Static Var Compensation (SVC), rectifier for drives applications, medium voltage drives, load commutating inverter and cycloconverter.

Key Specifications

T3441N52TOH is a phase control thyristor, disc (press-pack) from Infineon (eupec / IFBIP), rated 5200V, 3200A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	Infineon (eupec / IFBIP)
Repetitive peak off-state / reverse voltage VDRM, VRRM	5200 V
Average on-state current ITAVM	3200 A (TC = 85 °C)
Max. RMS on-state current ITRMSM	5030 A (TC = 85 °C)
Surge current ITSM (10 ms, 25 °C / Tvj max)	82000 A / 79000 A
I²t (10 ms, 25 °C)	33 500 x 10³ A²s
On-state voltage vT max. (4000 A, Tvj max)	1.7 V
Critical rate of rise of off-state voltage	2000 V/µs (5th letter H)
Clamping force	63 ... 91 kN
Max. diameter / contact diameter / height	151.5 mm / 100 mm / 26 mm
Datasheet	Available on this page (PDF)

Note: data taken from the Infineon (eupec / IFBIP) datasheet of T3441N series (4800 - 5200 V), which covers T3441N52TOH.
