BSM15GD100DInfineon - IGBT

BSM15GD100D Description

The Infineon Technologies (formerly Eupec) BSM15GD100D is an IGBT module rated at 1000 V and 150 A, available from USComponent. Components of this type are commonly used in variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent specializes in sourcing power modules and industrial electronic components, including legacy and hard-to-find parts for repair and maintenance. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the BSM15GD100D.

Target Applications

Infineon BSM15GD100D is used for High Power Switching, A.C. Motor Controls, D.C. Motor Controls, Uninterruptible Power Supply, Inverter for motor drive.

Key Specifications

Manufacturer	Infineon Technologies (formerly Eupec)
Configuration	Six-pack / three-phase bridge (6-in-1)
VCES	1000 V
IC nom	15 A

BSM15GD100D Video

Download BSM15GD100D Datasheet

Datasheet not available
