BSM150GB120DN2-E3256 Infineon - IGBT Module

BSM150GB120DN2-E3256 Description

The BSM150GB120DN2-E3256 is an IGBT module made by Infineon Technologies (formerly Eupec). You'll typically find it in variable-frequency drives, servo amplifiers, UPS systems, welding machines and solar or wind inverters. If you are repairing older equipment, we can usually find this exact part, including date codes that are no longer in production.

USComponent has been supplying power semiconductors since 2001, including discontinued and hard-to-find part numbers. Send us an RFQ for the BSM150GB120DN2-E3256 and we will reply with price, condition and lead time. Please check the manufacturer's datasheet to confirm ratings, package and pin-out before you order.

Summary of Features

Target Applications

Infineon BSM150GB120DN2-E3256 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

BSM150GB120DN2-E3256 is an eupec (Infineon) IGBT standard module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF). BSM150GB120DN2-E3256 is a variant of the basic type BSM150GB120DN2; the values are those listed for BSM150GB120DN2.

Parameter	Value
Manufacturer	eupec (Infineon Technologies)
Product type	IGBT standard module
Collector-emitter voltage VCES	1200 V
Collector current IC	150 A
VCE(sat) typ., Tvj = 25 °C	2.5 V
Total power dissipation Ptot	1250 W
Thermal resistance RthJC per arm	≤ 0.1 K/W
Package (outline)	IS5a

Technical document (PDF)  |  Request a quote for BSM150GB120DN2-E3256 (reply within 24 hours)
