MBN600GR12Hitachi - IGBT

MBN600GR12 Description

Hitachi MBN600GR12 is an IGBT rated at 1200 V and 600 A. Components of this type are commonly used in variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent specializes in sourcing power modules and industrial electronic components, including legacy and hard-to-find parts for repair and maintenance. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the MBN600GR12.

Target Applications

Hitachi MBN600GR12 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

Manufacturer	Hitachi
Configuration	Single IGBT module
VCES	1200 V
IC	600 A
Collector power dissipation	3570 W
VCE(sat)	2.2 V
Switching time	ton 1.0 µs / toff 1.2 µs / tf 0.4 µs
Outline	N-6
Status	Discontinued (successor: MBN600GR12A)

MBN600GR12 Video

Download MBN600GR12 Datasheet

MBN600GR12 PDF Datasheet
