A50L-0001-0326 Fuji Electric - IGBT Module
A50L-0001-0326 Description
Fuji Electric makes the A50L-0001-0326, a 600 V, 20 A IGBT module. Typical uses include motor drives, servo amplifiers, induction heating, welding power sources and grid-tie inverters.
We help engineers and repair technicians find parts like the A50L-0001-0326, including obsolete ones. Send a quick RFQ for current pricing and delivery. Before ordering, please confirm ratings and pin-out with the official datasheet.
Summary of Features
A50L-0001-0326 (Fuji Electric 6MBP20RTA060-01) is a 600 V / 20 A 6-in-1 intelligent power module.
- 600 V / 20 A, 6-in-1 IGBT-IPM with built-in gate drive
- Protection: under-voltage lockout and IGBT chip over-heating (all phases); over-current and alarm output (low side)
- Low-side shunt resistor for over-current sense (4.0 mΩ typ)
- Single 15 V pre-driver supply per phase
- Applications: servo amplifiers, motor drive inverters (FANUC spare part A50L-0001-0326)
Target Applications
Fuji Electric A50L-0001-0326 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.
Key Specifications
Fuji Electric equivalent: FANUC part number A50L-0001-0326 corresponds to the Fuji Electric module 6MBP20RTA060-01.
A50L-0001-0326 is a 600 V / 20 A intelligent power module (IGBT-IPM), FANUC spare-part number for the Fuji Electric 6MBP20RTA060-01. Source: manufacturer datasheet (detailed).
| Parameter | Value |
|---|---|
| Manufacturer | Fuji Electric |
| FANUC part number | A50L-0001-0326 |
| Fuji Electric part number | 6MBP20RTA060-01 |
| Product type | Intelligent power module (IGBT-IPM), R series |
| Configuration | 6-in-1 (3-phase inverter), built-in pre-drivers |
| Collector-emitter voltage (VCES) | 600 V |
| Collector current (IC) | 20 A DC, 40 A pulse (1 ms) |
| Collector power dissipation (PC) | 103 W (one transistor) |
| DC bus voltage (VDC) | 450 V max; 400 V recommended max |
| Collector-emitter saturation voltage (VCE(sat)) | 2.2 V max (IC = 20 A, terminal) |
| FWD forward voltage (VF) | 2.6 V max (IF = 20 A, terminal) |
| Switching time | ton 1.2 µs min, toff 3.6 µs max, trr 0.3 µs max (VDC = 300 V, IC = 20 A, Tj = 125 °C) |
| Over-current protection level (IOC) | 30 A min, 40 A typ (Tj = 125 °C) |
| IGBT chip over-heating protection (TjOH) | 150 °C min |
| Under-voltage protection (VUV) | 11.0 - 12.5 V |
| Pre-driver supply voltage (VCC) | 15 V typ (13.5 - 16.5 V) |
| Thermal resistance (Rth(j-c)) | 1.21 °C/W IGBT, 2.70 °C/W FWD (max) |
| Junction temperature (Tj) | 150 °C max |
| Operating case temperature | -20 to +100 °C |
| Isolation voltage (Viso) | AC 2500 V (1 min) |
| Weight | 85 g typ |
| Datasheet | Fuji Electric specification MS6M0713 (PDF on this page) |
Technical document (PDF) | Request a quote for A50L-0001-0326 (reply within 24 hours)
Related Part Numbers
| A50L-0001-0327 600V, 50A | A50L-0001-0328 600V, 50A | A50L-0001-0324 1200V, 75A | A50L-0001-0329 600V, 80A |
| A50L-0001-0330 600V, 80A | A50L-0001-0331 600(V) / 100(A) | A50L-0001-0332 600V, 160A | A50L-0001-0320 600(V) / 400(A) |
| A50L-0001-0314 1200V, 25A | A50L-0001-0306-RE 600V, 150A | A50L-0001-0306 600V, 150A | A50L-0001-0305-S 600V, 75A |
| A50L-0001-0333 600V, 160A | A50L-0001-0305 600V, 75A | A50L-0001-0335 600V, 100A | A50L-0001-0304-S 600V, 50A |
