7MBR50SB140-01 Fuji Electric - IGBT power module

Category: IGBT Modules

Specifications: 1400V, 50A

7MBR50SB140-01, Fuji, Fuji Power Transistor Module

Representative image – actual product may differ

We beat competitor's price with faster delivery.

For 6 pieces or more, submit your inquiry here, email to sales@uscomponent.com or call 1-281-968-0718

7MBR50SB140-01 Description

7MBR50SB140-01 is an IGBT module, PIM (converter + brake + inverter), 7 in one from Fuji Electric, rated 1400V, 50A.

USComponent supplies 7MBR50SB140-01 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Target Applications

Fuji Electric 7MBR50SB140-01 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

7MBR50SB140-01 is an IGBT module, PIM (converter + brake + inverter), 7 in one from Fuji Electric, rated 1400V, 50A. Source: manufacturer datasheet.

ParameterValue
ManufacturerFuji Electric
Inverter VCES1400 V
Inverter IC (Tc = 25 / 75 °C)75 / 50 A
Inverter ICP (1 ms, Tc = 25 / 75 °C)150 / 100 A
Inverter collector power dissipation360 W
Brake IC (Tc = 25 / 75 °C)35 / 25 A
Converter VRRM1600 V
Converter average output current IO50 A
Converter surge current IFSM (10 ms)520 A
Junction temperature Tj150 °C
Isolation voltageAC 2500 V, 1 min
DatasheetAvailable on this page (PDF)

Note: data taken from the Fuji Electric datasheet of Fuji Electric specification sheet MS6M0557, which covers 7MBR50SB140-01.

Note: Rated 1400 V / 50 A (Tc = 75 °C).

Technical document (PDF)  |  Request a quote for 7MBR50SB140-01 (reply within 24 hours)
