7MBR15NF-120 Fuji Electric - IGBT power module

7MBR15NF-120 Description

Fuji Electric 7MBR15NF-120 is an IGBT module rated at 1200 V and 15 A. It is built with a PIM layout, with the input rectifier, brake chopper and three-phase inverter in one package. Modules like this do the heavy switching in motor drives, UPS systems, induction heaters and renewable-energy inverters.

Looking for a replacement 7MBR15NF-120? USComponent can quote new and hard-to-find stock and ships worldwide. Request a quote for pricing and lead time, and double-check the datasheet to make sure it fits your application.

Summary of Features

Target Applications

Fuji Electric 7MBR15NF-120 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

Manufacturer	Fuji Electric
Configuration	PIM / CIB (converter + brake + inverter, 7-in-1)
VCES	1200 V
IC nom	15 A
Similar-rating parts	7MBR15SA120H, 7MBR15SL-120 (same nominal voltage and current rating, for reference only. Package, pinout and characteristics may differ; please compare datasheets to determine suitability)
