7MBP25RA120 Fuji Electric - IGBT power module

7MBP25RA120 Description

Fuji Electric 7MBP25RA120 is an intelligent power module (IPM) rated at 1200 V. It is built with a PIM layout, with the input rectifier, brake chopper and three-phase inverter in one package. Because the gate drivers and protection circuits are built in, it is popular in compact motor drives, servo amplifiers and appliance inverters. Production of many older modules has ended, but we keep sourcing them for repair and maintenance customers.

USComponent has sourced power semiconductors for maintenance teams and OEMs since 2001. For price and availability of the 7MBP25RA120, send us a request for quote. Please confirm the specifications against the manufacturer's datasheet before purchase.

Summary of Features

Target Applications

Fuji Electric 7MBP25RA120 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

7MBP25RA120 is a 1,200 V, 25 A intelligent power module (IPM), 7-in-1 (with brake) configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	Intelligent power module (IPM)
Configuration	7-in-1 (with brake)
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	25 A
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for 7MBP25RA120 (reply within 24 hours)
