6RI75E-080 Fuji Electric - Diode Module

6RI75E-080 Description

The 6RI75E-080 from Fuji Electric is a diode module with a 600 V / 75 A rating. Typical applications include AC-to-DC rectification in drives and power supplies, freewheeling paths and battery charging. If you are repairing older equipment, we can usually find this exact part, including date codes that are no longer in production.

Request a quote for the 6RI75E-080 and our team will get back to you with price, quantity available and lead time. We ship worldwide. As with any power device, please check the manufacturer's datasheet to confirm it matches your design.

Target Applications

Fuji Electric 6RI75E-080 is used for Inverter for AC Motors, Power supply units for DC motors, DC power supply units for battery chargers and General purpose DC power supply units.

Key Specifications

Manufacturer	Fuji Electric
Configuration	Six-pack power diode module (three-phase bridge rectifier), isolated
VRRM	800 V
Average output current IO	75 A (TC = 101 °C)
Surge current IFSM	1000 A (10 ms)
Forward voltage VFM max.	1.15 V @ 75 A
Isolation voltage	AC 2000 V (1 min)
Screw torque	M5: 2.5 - 3.0 N·m recommended (3.5 N·m max.)

6RI75E-080 Video

Technical document (PDF)  |  Request a quote for 6RI75E-080 (reply within 24 hours)
