6MBP75RS-060Fuji Electric - IGBT power module

6MBP75RS-060 Description

The Fuji Electric 6MBP75RS-060 is an intelligent power module (IPM) rated at 600 V and 75 A, available from USComponent. Typical applications for this type of device include compact motor drives, servo amplifiers and inverter-based equipment, where the IPM combines power switches with built-in gate drive and protection circuitry.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the 6MBP75RS-060.

Target Applications

Fuji Electric 6MBP75RS-060 is used for General Purpose Inverter, Uninterruptible Power Supply, Servo & Spindle Drive for CNC Machine Tools, Robotics (Servo Drive for Robots), Switching Power Supplies for Welding Machines.

Key Specifications

Manufacturer	Fuji Electric
Configuration	IPM, six-pack (6-in-1)
VCES	600 V
IC nom	75 A
Similar-rating parts	PM75CFE060, PM75CSD060, 6MBP75RA060, 6MBP75NA060 (same nominal voltage and current rating, for reference only. Package, pinout and characteristics may differ; please compare datasheets to determine suitability)

6MBP75RS-060 Video

Download 6MBP75RS-060 Datasheet

Datasheet not available
