6MBI200L-060 Fuji Electric - IGBT Module

6MBI200L-060 Description

Fuji Electric makes the 6MBI200L-060, an IGBT module. Inside, it has six switches arranged as a three-phase bridge (6-in-1). You'll typically find it in variable-frequency drives, servo amplifiers, UPS systems, welding machines and solar or wind inverters.

Looking for a replacement 6MBI200L-060? USComponent can quote new and hard-to-find stock and ships worldwide. Request a quote for pricing and lead time, and double-check the datasheet to make sure it fits your application.

Summary of Features

Target Applications

Fuji Electric 6MBI200L-060 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

6MBI200L-060 is a 600 V, 200 A IGBT module, six-pack (6-in-1) configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	Six-pack (6-in-1)
Collector-emitter voltage (VCES)	600 V
Collector current (IC)	200 A
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for 6MBI200L-060 (reply within 24 hours)
