6MBI100FC-060 Fuji Electric - IGBT Module

6MBI100FC-060 Description

Rated at 600 V and 100 A, the Fuji Electric 6MBI100FC-060 is an IGBT module. The module contains six switches arranged as a three-phase bridge (6-in-1). Modules like this do the heavy switching in motor drives, UPS systems, induction heaters and renewable-energy inverters. Production of many older modules has ended, but we keep sourcing them for repair and maintenance customers.

Looking for a replacement 6MBI100FC-060? USComponent can quote new and hard-to-find stock and ships worldwide. Request a quote for pricing and lead time, and double-check the datasheet to make sure it fits your application.

Summary of Features

Target Applications

Fuji Electric 6MBI100FC-060 is used for General Purpose Inverter, AC and DC Servo Drive Amplifier and Uninterruptible Power Supply, Switching Power Supplies for Welding machine.

Key Specifications

6MBI100FC-060 is a 600 V, 100 A IGBT module, six-pack (6-in-1) configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	Six-pack (6-in-1)
Collector-emitter voltage (VCES)	600 V
Collector current (IC)	100 A
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for 6MBI100FC-060 (reply within 24 hours)
