6DI30A-120Fuji Electric - Darlington Module

6DI30A-120 Description

The Fuji Electric 6DI30A-120 is a Darlington transistor module rated at 500 V and 300 A. Components of this type are commonly used in motor drives, UPS systems and power supplies; transistor modules of this type are largely superseded by IGBTs in new designs but remain essential for maintaining installed equipment.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the 6DI30A-120.

Summary of Features

Target Applications

Fuji Electric 6DI30A-120 is used for high-power traction inverters and choppers, medium-voltage motor drives, static VAR compensators and other high-power converters.

Key Specifications

6DI30A-120 is a 1,200 V, 30 A power transistor (bipolar Darlington) module, six-pack configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	Power transistor (bipolar Darlington) module
Configuration	Six-pack
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	30 A
Datasheet	Available on this page (PDF)
